SPECIFICATIONS:
- High Torque High Speed Brushless Servo
-
IP67 Rated WATERPROOF: 7 Point Seals
- Magnetic Angle Sensor
- Pulse Width Modulation Control
- Voltage: 12V - 16.8V
- Internal: Steel Gears / All CNC Aluminum Casing
- Bearing Type: 3 Ball Bearings / Weight: 3.12oz
- LWH: 1.57 x .78 x 1.63 / 40x20x41.5mm
- Torque: 640oz (46.1kg)@ 12v / 765oz (55.1kg)@ 14.4v / 860oz (61.9kg)@ 16v / 917oz (66kg)@ 16.8v
- Speed: .13sec @ 12v /.11sec @ 14.4v / .10sec @ 16v / .09sec @ 16.8v
- Spline: 25T
- Dead Band Width: 2¦Ìs
- Unload Current: 450mA@12.0V
530mA@14.4V
600mA@16.0V
630mA@16.8V -
Load Current: 4600mA@12.0V
4900mA@14.4V
5200mA@16.0V
5500mA@16.8V
Item# REEFS124
Here at Iron City EVERY Package Shipped is signed by the employee that packs it!
We Strive to Ship Same Day!
